Home GALVANISED PLAIN & CORRUGATED

GALVANISED PLAIN SHEETS

At Gandhi & Co., we take pride in being called the suppliers and distributors of high-grade galvanised plain steel sheets in Mumbai. Over the past years, we have been able to provide high-quality Galvanized sheets to our clients with the guarantee and after-sales support.

Galvanized Sheets and Galvanized Carbon Sheets are included in this category. The sheets available are utilized in a variety of construction projects. These galvanised corrugated roofing sheets are well-liked for their durability, corrosion resistance, and smooth finish. These sheets are available in a variety of sizes and dimensions, and they can be further tailored to meet our client’s needs. The following is a detailed summary of the available sheets.

QUALITY IS OUR TOP PRIORITY

As the leading plain galvanised iron sheet supplier in Mumbai, we always ensure the best quality and performance from all of our products. Galvanized Steel Products, such as galvanised plain steel sheets & Galvanized Steel plates, Galvanized Steel Coil, and galvanised corrugated steel sheets, are perfect for a variety of industrial applications due to their unsurpassed quality and performance. Furthermore, the vendors manufacture Galvanized Steel Metal sheets, Coils, and Plates using high-quality materials, ensuring great durability, tensile strength, and resistance to harsh situations.

As India’s most sought-after galvanized plain steel sheet manufacturers, our partners provide a high-quality range of Galvanized sheets. As a leading Galvanized Sheet Exporter, we can provide a superior selection of Galvanized Sheets to our clients. We build these products in accordance with international quality standards, and as one of the first Galvanized Steel Sheet Suppliers in our industry, we provide these products to clients in the most efficient method possible.

Galvanized sheets are available mainly in IS277 and can be made in order in a variety of options like Regular strangle, Skin pass, GalvAlum, etc with Zinc coating from 80 to 275 gsm and in hardness from 250 to 550MPa. Can offer corrugated sheets in GP plain up to 1mm thickness and in any length required. These sheets are known for their strength, durability, corrosion resistance, and great operational performance.

COMPETENT AND WELL-TRAINED STAFF

Being the finest corrugated roof sheet suppliers in Mumbai, our qualified staff is trained to educate and engage with any of our client’s needs, and we’ve built long-term relationships with each of them. From sourcing the finest material with the best quality to the delivery of high-grade products, we take care of the entire process from start to end.

Our relationships with our clients are maintained with the goal of a long-term business connection, and we now have a large number of loyal clients who have been purchasing from us for more than 30 years.

Thickness Range 0.10 to 3 mm
Widths upto 1250 mm
Coating 90-275 gsm
Users / Application Automobile * White Goods *Lock Forming* HVAC *Door Windows *Insulation & Panels *Structural Engineering * Furniture *Roofing, Cladding * Parition Profiles & Roll Profile Forming
Temper Stretch / non Stretch leveled / Skin Passed
Grades Full hard / CQ / D/EDD /LFQ (Upto 1.25mm)
Hardness Hard : 90HRB (+ / -5) Soft: 60HRB (+ / -5)
Standard IS 277, JIS3302, ASTM A 653, DIN 17162
Surface Finish Bright / Matte (regular /small/big/suppressed sprangles)
Surface treatment Chromated / un-chromated & oiled

Technical Specs: IS 277-2003

Chemical C Mn P S Al N
All Figures in max %
Ordinary 0.15 0.60 0.055 0.055 0.02 70 ppm
Drawing 0.12 0.50 0.040 0.055 0.02 70
Deep Drawing 0.10 0.45 0.035 0.035 0.02 70
Extra deep drawing 0.08 0.40 0.030 0.030 0.02 70
Mechanical YS Mpa TS Mpa El % (min) Hardness HR (30t)
Drawing 350 270-430 23 60-68
Deep Drawing 310 270-400 26 55-60
Extra deep drawing 280 270-370 32 50-55

GALVANISED CORRUGATED SHEETS

Thickness Range 0.10 to 0.80 mm
Widths 665/720/740/780/800/875/1065 mm
Length 1829-4877 mm
Temper Hard / Soft, Stretch Levelled (0.6-0.8mm) Soft Non Stretch Levelled (0.10-0.75mm)hard
Surface Finish Regular / Small to big Sprangles
Zn Coating 90-275 gsm
Corrugation 11-14 dips or as specified
Specification IS 277, JIS G3316, Ethopian ES C.D7.001 or Equivalent
Grade Roofing (full hard)
Hardness 90 HRB (up to 0.75mm) hard & 60 HRB (0.6-0.8mm) soft

Technical Specs: JIS G 3316-1987

Chemical C Mn Ph S Al N
Commercial 0.15 0.60 0.05 0.05 0.02 90 ppm
Grade With before Corrugation With before Corrugation Depth Pitch No of Corrugation
1 762 mm 665 mm 18 76.2 8
1 914 mm 800 mm 18 76.2 10
1 1000 mm 875 mm 18 76.2 11
1 1220 mm 1065 mm 17.5 75 14
Mechanical YS Kg/mm2 TS Mpa Kg/mm2 El % (min)
Ordinary
St 34 34-42 21 23
St 42 42-50 24 26
St 50 50-60 30 32
